Fax ATA Installation Guide

Modified on Mon, 6 Oct at 9:31 AM

Overview

The Pangea Fax ATA allows you to connect a traditional fax machine to your internet-based fax service.

Once connected, your faxes will send and receive through your VoIP network rather than a phone line.

• 1 × Pangea Fax ATA (Grandstream HT801 or HT812)

• 1 × Power Adapter

• 1 × Ethernet Cable

• 1 × Telephone Line Cord

✅ Ensure you have:

• An active internet connection (router or switch port available)

• Your fax machine powered and ready

• Do NOT connect the ATA to a wall phone jack — it connects only to your fax machine

(illustration placeholder: top-down image labeling “Power,” “LAN/WAN,” and “Phone/FXS Port”)

PORT	LABEL	FUNCTION
LAN / WAN	“LAN” or “Internet”	Connects to your router or switch
☎ PHONE / FXS	“Phone” or “Port 1”	Connects to your fax machine
POWER	“DC 12V”	Connects to power adapter

(illustration placeholder: network diagram showing router → ATA → fax machine)

1. Internet: Plug one end of the Ethernet cable into your router or network switch, and the other end into the LAN/WAN port on the Fax ATA.

2. Fax Machine:Connect a telephone cord from your fax machine’s LINE or PHONE jack to the ATA’s FXS port (Port 1).

3. Power: Plug the power adapter into the ATA and then into a wall outlet.

4. Wait about 2 minutes — the Power and Internet lights will turn solid, and the Phone light will illuminate once the fax machine is detected.

(illustration placeholder: close-up of ATA LEDs showing correct lights)

LED INDICATOR	STATUS	MEANING
Power	Solid	Device is on
Internet	Solid	Connected to Network
Phone	Solid	Fax Line is Ready
ALL LEDs	Blinking	Registering or transmitting fac
Internet Light	OFF	Check your ethernet cable or router port.

1. Power on your fax machine.

2. Send a test fax to a known working number (such as a Pangea fax test number).

3. Once successful, ask someone to fax you back to confirm inbound faxing works.

✅ If both send and receive tests pass, your installation is complete!

PROBLEM	CAUSE	SOLUTION
No power Light	Unplugged	Check outlet and power adapter
No internet light	Cable or router issue	Reseat Ethernet cable, reboot router
No dial tone on fax	Loose cable	Check phone cord to FXS port
Fax fails to send	Weak signal / wrong mode	Ensure fax machine ECM = Off and Baud = 14,400 or lower
Registration failed	No network / credentials issue	Contact support
